ACCESS - Triple Attenuvert Bias

Regular price $25.00 $0.00 Unit price per

ACCESS provides users with attenuation/attenuversion and bias controls for three video signals. It may be used with a full color RGB set or with three separate luma/control voltages.

Using the Attenuvert knobs controls the input signal from -1 to +1 only. The Bias knobs apply an offset from -1volt CCW to +1volt CW.

The top-most input is normalled to a 1 volt reference signal which allows the module to be used as a bipolar -1 volt to +1 volt control voltage when nothing is plugged into the inputs. All inputs are normalled as 1volt>R>G>B.

8 HP
41 mm deep

Current Draw:
30 mA +12V
30 mA -12V
0 mA 5V

BOM & Build Guide
