ABC - Dual A+B-C Video Mixer
ABC - Dual A+B-C Video Mixer
Foxing Hour

ABC - Dual A+B-C Video Mixer

Regular price $22.00 $0.00 Unit price per

ABC offers two sets of sub-circuits, each with two positive inputs (A and B) and one negative input (C). Perform simple additive and subtractive mixing with video luma signals.

Mathematical equations can be preconfigured based on different BOMs. Builders will have the choices of, but not limited to the following:
(A+B)/2-C (Recommended)

Assembled units use the (A+B)/2-C configuration. It is also the recommended config for builders unsure about which to choose.

4 HP
47 mm deep
Current Draw:
35 mA +12V
30 mA -12V
0 mA 5V

BOM(s) & Build Guide(s)

 Captures courtesy of Matthew Rempes:
